Operational Amplifiers Card

This practical resource allows students to investigate operational amplifier circuits through a range of activities.

The practical activities based around the Operational Amplifiers Card are available within the digital curriculum materials provided with our Electronics Study Trainer.

Practical tasks include the following:
  • Investigating a voltage comparator circuit
  • Building and testing an inverting amplifier
  • Building and testing a non-inverting amplifier
  • High Frequency Performance of an Operational Amplifier
  • Fault-finding operational amplifier circuits

Please Note: This card requires access to an Electronics Study Trainer (320-00).

How to order

Product:
Operational Amplifiers Card
Code:
320-31

Please call LJ Create at
+44 (0)1603 748001 or
email info@ljcreate.co.uk.

A member of our staff will be happy to advise you with your order and provide you with further options where appropriate.
