Multiplexer/Demultiplexer Digital Systems Card

This practical resource introduces students to digital multiplexers and demultiplexers through a range of practical activities.

The practical activities based around the Multiplexer/Demultiplexer Digital Systems Card are available within the digital curriculum materials provided with our Electronics Study Trainer.

Practical tasks include the following:
  • Investigating a digital multiplexer
  • Scanning multiplexer inputs using a binary counter
  • Building and testing a multiplexer/demultiplexer system
  • Clocking and synchronization
  • Fault-finding multiplexer/demultiplexer systems

Please Note: This card requires access to an Electronics Study Trainer (320-00).

How to order

Product:
Multiplexer/Demultiplexer Digital Systems Card
Code:
320-45

Please call LJ Create at
+44 (0)1603 748001 or
email info@ljcreate.co.uk.

A member of our staff will be happy to advise you with your order and provide you with further options where appropriate.
