Analogue Integrated Circuits Card

This practical resource allows students to investigate a variety of analogue integrated circuits through a range of activities.

The practical activities based around the Analogue Integrated Circuits Card are available within the digital curriculum materials provided with our Electronics Study Trainer.

Practical tasks include the following:
  • Investigating IC sensors
  • Comparing linear and switch mode voltage regulators
  • Testing a switched capacitor filter
  • Investigating the operation of a phase locked loop
  • Using analogue switches
  • Fault-finding analogue integrated circuits

Please Note: This card requires access to an Electronics Study Trainer (320-00).

How to order

Product:
Analogue Integrated Circuits Card
Code:
320-32

Please call LJ Create at
+44 (0)1603 748001 or
email info@ljcreate.co.uk.

A member of our staff will be happy to advise you with your order and provide you with further options where appropriate.
