Advanced Electronics Experiment Platform

This unit provides power supplies and connection facilities for the complete range of advanced electronics circuit boards. It can operate either in standalone mode, or via a USB interface to a host PC. Facilities are provided for switching of faults into most study modules.

Alignment of each circuit board on the Advanced Electronics Experiment Platform (300-01) is achieved by means of an integral guide-rail system. A locking mechanism ensures a reliable and safe electrical contact.

The platform meets the power supply requirements for all advanced electronics study modules.

The following power supply outputs are provided:
  • 0-12V Variable DC
  • +5V DC
  • -5V DC
  • +12V DC
  • -12V DC
  • 12-0-12V 50/60 Hz AC
