Disc and Drum Braking System Trainer

This real component-based trainer provides students and instructors with the opportunity to demonstrate and investigate the operation of a typical automotive braking system.

The Disc and Drum Braking System Trainer (763-01) is designed to allow access to both disc and drum brake components, as well as providing the opportunity to understand the operation of the hydraulic circuit.

Disc and Drum Braking System Trainer – Typical practical tasks include:
  • Friction brake theory
  • Drum brake components and operation
  • Disc brake components and operation
  • Drum brake machining
  • Disc measurement and inspection
  • Handbrake components and operation
  • Handbrake servicing
  • Brake problem diagnosis
  • Mount brake drum on lathe; machine braking surface
  • Check handbrake cables and components for wear, rusting, binding, and corrosion
  • Adjust calipers with integrated handbrake system
  • Diagnose poor stopping, noise, pulling, grabbing, dragging, or pedal pulsation concerns
