Sequential Logic Card
This practical resource introduces students to sequential logic through a range of practical activities.
The practical activities based around the Sequential Logic Card (320-42) are available within the digital curriculum materials provided with our Electronics Study Trainer.
Practical tasks include the following:
- Investigating a D-type flip-flop
- Investigating a J-K flip-flop
- Binary counter operation
- Frequency division
- Shift register operation
- Ring counter operation
- Testing and fault-finding sequential logic systems
Please Note: This card requires access to an Electronics Study Trainer (320-00).
How to order
Product:
Sequential Logic Card
Code:
Please call LJ Create at
+44 (0)1603 748001 or
email info@ljcreate.co.uk.
A member of our staff will be happy to advise you with your order and provide you with further options where appropriate.
