Heavy Vehicle Electrical Systems Panel Trainer

The trainer provides students and instructors with the opportunity to demonstrate, investigate and fault-find a simulation of typical diesel electrical systems. The trainer is designed to allow access to a variety of test points for vehicle electrical components, as well as provide an understanding of the overall system layout and configuration.

To facilitate the development of techniques in diagnostics and fault-finding skills, the Heavy Vehicle Electrical Systems Panel Trainer (757-01) includes a range of fault-insertion options to simulate typical real-world system malfunctions.

Typical practical tasks include:
  • Battery and fuses
  • Starter and solenoid
  • Horn and relays
  • Park, tail and headlights
  • Turn signal and hazard warning lights
  • Brake and back up lights
  • Auxiliary lighting
  • Alternator charging systems
  • Windshield wiper system
  • Cold starting systems
  • Troubleshooting

Did you find what you were looking for?
Take a look at our full range of automotive training resources

How to order

Product:
Heavy Vehicle Electrical Systems Panel Trainer
Code:
757-01

Please call LJ Create at
+44 (0)1603 748001 or
email info@ljcreate.co.uk.

A member of our staff will be happy to advise you with your order and provide you with further options where appropriate.
